bomb basket

invented designed and Made in India

Bomb Basket designed and developed by us is to handle and counter a minimum of 2 Kg. TNT or Equivalent.

bomb basket with trolley

invented, designed and Made in India

Model - PCB 137B23B

Bomb Basket designed and developed by us is to handle and counter a minimum of 2 Kg. TNT or Equivalent. Bomb Basket is fully capable to contain the blast impact without affecting the surroundings and human lives. The construction of a trolley allows the Bomb Recovery operation even in congested are or off-road tough terrains.

technical specifications

The explosive rating of bomb basket will be minimum 02 Kg. TNT equivalent for single use.
The weight of the basket is maximum 300 Kg.
The diameter of the opening of the bomb basket is minimum 18 inches.
The height of the bomb basket is minimum 24 inches.
The bomb basket prevent any horizontal displacement / movement of fragments.
The Bomb Basket direct fragments surrounding the explosive upward through the opening on top.
The Bomb basket is not made of any material which may act as secondary fragments. Cart/trolley for movement and should have tools to facilities easy loading and uploading.

trolley specifications

The BOMB Trolley is designed for safe transportation of suspected device to contain explosives up to 2kg TNT.
The construction of the Trolley have more advantages for operations in Hill Area & off-road conditions due to its light weight it can easily be towed with a Smaller Vehicle Like a jeep or any SUVs.
Can be used multiple times if an explosion occurs in the Trolley as the basket can be replaced
The weight of the Trolley is 600 Kgs (approx.)
The Dimensions are: Height - 1.3 meters Length - 2.0 meters Width - 1.55 meters
